17. Composition tables
The tables below indicates which components are required for assembling a scaffold up to a certain height.
Make sure that these components are present.
Composition table Custers Handy / CR 0.7m, freestanding, available in lengths 1.8m / 2.50m / 3.10m(Handy only)
Working height [m] 4 5 6 7 8 9 10 11 12 13 14
Platform height [m] 2 3* 4 5 6 7 8 9 10 11 12
Description Part number Kg
8-Rung frame 700 9501.200.012(CR) 8,5 2 4 4 6 6 8 8 10 10 12 12
4-Rung frame 700 9501.200.022(CR) 4,8 2 0 2 0 2 0 2 0 2 0 2
Locking pin 9501.410.162 0,06 4 4 8 8 12 12 16 16 20 20 24
Toe board 700 9501.200.092 1,2 2 2 2 2 2 2 2 2 2 2 2
Toe board bracket 9501.800.087 0,2 4 4 4 4 4 4 4 4 4 4 4
Caster + spindle rubber
Caster + spindle plastic
Caster + spindle plastic CR
9501.510.010
9501.510.050
9501.510.065
7,2
6,5
4,8
4 4 4 4 4 4 4 4 4 4 4
Length 1,8m Length 2,5m Length 3,05m
Description Part number Kg Part number Kg Part number Kg
Handy platform with hatch wood
CR platform with hatch wood
Handy platform with hatch plastic
9501.310.015
9501.316.015
9501.311.015
12,3
12,3
11,9
9501.310.025
9501.316.025
9501.311.025
20,4
16,3
15,3
9501.310.035
9501.311.035
25,3
17,7
1 1 2 2 3 3 4 4 5 5 6
Horizontal 9501.200.058(CR) 2,0 9501.200.030(CR) 2,7 9501.200.040 3,2 4 4 8 8 12 12 16 16 20 20 24
Diagonal 9501.200.043(CR) 2,5 9501.200.056(CR) 3,1 9501.902.056 3,6 2 4 4 6 6 8 8 10 10 12 12
Mobile Guard 9501.800.180 4,7 9501.800.250 5,3 9501.800.310 5,8 2 2 2 2 2 2 2 2 2 2 2
Toe board longitudinal side 9501.200.086 2,5 9501.200.080 4,9 9501.902.080 6,2 2 2 2 2 2 2 2 2 2 2 2
Horizontal/diagonal 9501.200.048(CR) 2,1 9501.200.052(CR) 2,8 9501.200.054 3,3 1 1 1 1 1 1 1 1 1 1 1
ONLY INDOOR USE Kg
Outrigger small
9501.410.100
9501.430.200
6,6 4 4 4 4
Outrigger large
9501.420.100
9501.430.210
9,4 4 4 4 4 4 4 4
INDOOR / OUTDOOR USE Kg
Outrigger small
9501.410.100
9501.430.200
6,6 4 4 4 4 x x x x
Outrigger large
9501.420.100
9501.430.210
9,4 4 4 4 x x x x
X = outside use prohibited, unless anchored.
Note: the table is based on a working level at the indicated platform height, fitted with guardrails, knee railings, toe boards and resting levels on each 2 meter the height fitted
with guardrails and knee railings. To convert a rest level into a working level you need: 4 x toe board bracket, 2 x toe board longitudinal side and 2 x toe board 700.
