8. Assembling the narrow mobile scaffold tower
(3,5,7,9,11 m)
1: Insert both casters into the 8-rung
frame; and make sure that the
casters are properly secured;
2: Place the horizontal braces on the
uprights of the frame;
3: Insert both casters into the 8-rung
frame; and make sure that the
casters are properly secured;
4: Place the horizontal braces on the
uprights of the frame;
5: Place the horizontal/diagonal brace on
the uprights of the frame;
6: Place the (temporary) platform (on the
5
th
rung from the top); slide both
blow-away protections under the rung;
Temporary
platform
1
2
3
4
5
6
