23
7: Place both 8-rung frames;
8: Place locking pins between the
frames themselves;
9: Place both diagonal braces;
10: Place both Mobile Guard guardrail
frames on the upper rung;
11: Place the platform with hatch (on the
5
th
rung from the top) and slide
both blow-away protections
under the rung;
12: Remove the temporary platform
13: Place 2 diagonals
14: Lock the brakes and set the
scaffold level by twisting the
spindle nut of the casters;
12
7
8
9
10
11
13
14
