CUSTERS CR 700 - Assembling the Wide Mobile Scaffold Tower (3,5,7,9,11 m)

10. Assembling the wide mobile scaffold tower
(3,5,7,9,11 m)
1: Insert both casters into the 8-rung
frame; and make sure that the casters
are properly secured;
2: Place the horizontal braces on the
uprights of the frame;
3: Insert both casters into the 8-rung
frame; and make sure that the casters
are properly secured;
4: Place the horizontal braces on the
uprights of the frame;
5: Place the horizontal/diagonal brace;
6: Place both diagonal braces;
7: Place the (temporary) platform (on the
5
th
rung from the top); slide both
blow-away protections under the rung;
Temporary
platform
1
2
3
4
5
6
7
