Custom Audio Electronics TK302 - Page 45

4
5
Unscrew the fixing pins and take off the fixed blade and the spring.
Fix the paper mouth group for the BURSTER configuration
by using the screws previously removed.
NOTE:
For ease of reference, for model with triple feeder is represented only the printer group without triple feeder.
45
