WARNING!
MOVING PARTS
PUSH HERE
TO CLOSE
1
2
3
4
6
5
PRINTER COMPONENTS
A. KPM216H-II Front external view
1- Printing head set
2- Opening lever of head set
3- Roller cover
4- Paper exit
(1)
5- Lock/Unlock button of motorization cover
6- Motorization cover
NOTE
(1) :
Available in two versions: horizontal or vertical (option 0090) paper delivery
User Manual KPM216H II
