TO OPEN
TWIST
TO LOCK
PUSH
Status
LF
FF
Reset
n
e
a
r
p
a
p
e
r
e
n
d
s
e
n
s
o
r
www.custom.biz
PAPER LOAD
1
2
SX
2
DX
3
6
4
5
7
8
9
10
11
12
13
B. KPM216H-II - Rear external view
1- Paper load
2- Paper feed guides (adjustable)
3- Status led
4- Feed key
5- Print key
6- Reset key
7- External near paper end sensor connector
8- Motorization cover
9- Printing head set
10- Opening lever of head set
11- Tilting paper holder
12- Paper ejector rollers unit
13- Roller cover
