1. INSTALLATION AND USE
41-
DPT100-B/I/BT
1
2
2
B
1
AA
• remove the battery pack (2) by lifting the battery removal tape (1) (see fig. 1.6).
• insert the 5 batteries
(7)
inside the compartment following the layout indicated in fig. 1.7 and re-position the
battery removal tape;
(7)
Note: when inserting the batteries, make sure the + and – signs are positioned correctly.
• reclose the battery compartment by tightening the fastening screws.
(Fig.1.5)
(Fig.1.6)
(Fig.1.7)
