ASSEMBLY & ADJUSTMENTS (cont.)
2. To set the 135 degree stop, loosen fence lever “A” and slide fence back completely and
re-tighten lever “A”. Place a 45 degree angle against the fence and use the provided 2.5mm
Hex Wrench to adjust the 135 degree set screw against the stop. NOTE: The set screw is
set deep into the angled hole at the factory. If necessary, use a flashlight to locate it.
See FIG 20 and FIG 21
NOTE: These positive stops enable you to quickly position the table to the 90 and 135 degree
settings. After successful adjustments, tilt fence back to 90 degrees and lock into position.
