TECHNICAL SPECIFICATIONS
Model M550L M750L M1100XL
Capacity (VA) 550 750 1100
Capacity (Watts) 440 600 880
INPUT
Input Voltage Range 90Vac – 150Vac
Input Frequency Range 50/60Hz ± 3Hz Auto-sensing
Input Plug Type NEMA 5-15P
OUTPUT
Output Receptacles NEMA 5-15R (Hospital Grade)
Output Voltage 120Vac ± 5%
Output Frequency 50/60Hz ± 1%
Output Waveform Simulated Sine Wave
Transfer Time (Typical) < 10ms
Overload Protection Internal Current Limiting, Circuit Breaker
SURGE PROTECTION AND FILTERING
Lightning / Surge Protection Yes
BATTERY
Replaceable Battery Pack RB1270X2E RB1270X3A RB1290X3B
Extended Runtime No No Yes (Max. 2)
Sealed Maintenance Free Yes
Recharge Time (Typical) 8 Hours
WARNING DIAGNOSTICS
Indicators LCD Display, LED Indicators (Power On)
Audible Alarms On Battery, Low Battery, Overload, UPS Fault
ENVIRONMENTAL
Operating Temperature 32 °F to 104 °F ( 0 °C to 40 °C)
Operating Relative Humidity 0 to 95% Non-condensing
Storage Temperature 5 °F to 113 °F ( -15 °C to 45 °C)
Storage Relative Humidity 0 to 95% Non-condensing
MANAGEMENT
Connectivity Ports (1) USB Port, (1) Serial Port
Software PowerPanel® Business
PHYSICAL
Dimensions (WxHxD) 5.4” x 6.4” x 13.7” 6.7” x 8.7” x 17”
Weight (lb/kg) 30.1lbs 52.8lbs 54.0lbs
SAFETY
Max. Current Leakage
< 100µA
Conformance Approvals UL1778 (CSA C22.2 No 107.3), UL60601 tested , FCC Part15 Class B
