CyberPower MBP15A6 User Manual

Copyright © 2014 CyberPower Systems, Inc.
8
TECHNICAL SPECIFICATIONS
Model
MBP15A6
MBP20A6
MBP30A5
Configuration
Form Factor
>1U 19” rack-mounting with multi-position mounting
Installation
19” rack horizontal or
vertical mounting on CyberPower RT UPSs
Cascading
Yes,
NEMA 15A output socket
Yes,
NEMA 20A output socket
Yes,
NEMA 30A output socket
Input
Input Voltage Range
100~125Vac*
100~120Vac*
Input Current Rating (Derated)
12A
16A
24A
Plug To Utility Power
(1) NEMA 5-15P
(1) NEMA 5-20P
(1) NEMA L5-30P
Outlet for UPS Input Power
(1) NEMA 5-15R
(1) NEMA 5-20R
(1) NEMA L5-30R
Plug To UPS Output
(1) NEMA 5-15P
(1) NEMA 5-20P
(1) NEMA L5-30P
Output
Transfer Time (Typical)
< 4ms
Outlets
(6) NEMA 5-15R
(6) NEMA 5-20R
(5) NEMA 5-20R
Status Indicators
LED Indicators
Normal (Green), Bypass (Red)
Physical
Dimensions H x W x D (mm)
2 x 17 x 3in. (5.1 x 43.3 x 7.6cm)
Net Weight (kg)
3.5lbs(1.6kg)
4.4lbs(2kg)
5.9lbs(2.7kg)
Cord Length--Plug To Utility Power
6ft(1.8m)
Cord Length--Plug To UPS Output
3.3ft(1m)
Environment
Operating Temperature
32℉ to 104℉ ( 0℃ to 40℃)
Operating Relative Humidity
0 to 90% Non-Condensing
*) 100V are derated by 20%, 110 V/115V are derated by 10%
CyberPower Systems Inc.
www.cpsww.com
Entire contents copyright
©
2014 CyberPower Systems Inc., All rights reserved. Reproduction in whole or in part
without permission is prohibited. PowerPanel
®
Business Edition and PowerPanel
®
Personal Edition are trademarks of
CyberPower Systems Inc.

CyberPower MBP15A6 Specifications

General

PDU types	-
Product color	Black
Rack capacity	1U
Housing material	Steel
Maximum current	15 A
Nominal input voltage	100-125 V
Nominal output voltage	120 V
Power plug	NEMA L5-15P
AC outlet types	NEMA 5–15R
AC outlets quantity	6 AC outlet(s)
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Cable length	1.82 m
Certification	UL60950_1, cUL
Sustainability certificates	RoHS

Weight and Dimensions

Weight	1600 g
Dimensions (WxDxH)	431.8 x 76.2 x 50.8 mm
