CyberPower PDU15B8R User Manual

Basic Series
Product Features
Front View
Back View
A B C D
A B
C
A. Mounting Bracket
B. Back Outlets
C. External Site Ground
A. Mounting Bracket
B. Circuit Breaker
C. Front Outlets
D. AC Power Cord
E. Cord Retention Tray
Screw Holes
EE
Technical Specifications
For information on Cyberpower products, visit www.cyberpower.com
8
Model Name
PDU15B2F8R
PDU15B2F10R
PDU15B2F12R
PDU15B4F8R
PDU15B4F10R
PDU15B4F12R
PDU15B6F8R
PDU15B6F10R
PDU15B6F12R
PDU20B2F8R
PDU20B2F10R
PDU20B2F12R
PDU20B4F8R
PDU20B4F10R
PDU20B4F12R
PDU20B6F8R
PDU20B6F10R
PDU20B6F12R
PDU20BT2F8R
PDU20BT2F10R
PDU20BT2F12R
PDU20BT4F8R
PDU20BT4F10R
PDU20BT4F12R
PDU20BT6F8R
PDU20BT6F10R
PDU20BT6F12R
Input
Voltage
Max current 15 A
Circuit Breaker 15 A
Plug Type NEMA 5-15P NEMA 5-20P NEMA L5-20P
Output
Voltage
Current 15 A
Outlet Type NEMA 5-15R
Indicators
LED Indicators
M
eter Readout
Physical
Environmental
Humidity
Altitude
Temperature
Safety Approvals
Certifications
Warranty
ETL (test followed UL 1363)
RoHS
Lifetime
Operating 0 to 95% Non-condensing
Non-Operating 0 to 95% Non-condensing
Operating 0ft to 10,000ft
Non-Operating 0ft to 50,000ft
Operating 32F to 95F
Non-Operating 5F to 113F
N/A
17.5" x 2.25" x 1.75" / 44.5 x 5.72 x 4.45 cm
N/A
100 ~ 125 V
20 A
NEMA 5-20R
100 ~ 125 V
20 A
20 A
15 ft
Power Cord Length
Dimension (WxDxH)

CyberPower PDU15B8R Specifications

General

Maximum current	15 A
AC input frequency	50 - 60 Hz
Nominal input voltage	120 V
Power plug	NEMA 5–15P
AC outlet types	NEMA 5–15R
AC outlets quantity	8 AC outlet(s)
PDU types	Basic
Product color	Black
Rack capacity	1U
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m
Storage temperature (T-T)	-15 - 45 °C
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Certification	UL1363, CSA C22.2
LED indicators	Yes

Weight and Dimensions

Weight (imperial)	3.5 lbs
Dimensions (W x D x H) (imperial)	17.5 x 1.5 x 1.75 \
