CyberPower PDU15B8R User Manual

Metered Series
Product Features
Front View
Back View
A B C D
A B
C D
A. Mounting Bracket
B. Back Outlets
C. External Site Ground
A. Mounting Bracket
B. Circuit Breaker
C. LED Meter Readout
D. Front Outlets
D. AC Power Cord
E. Cord Retention Tray
Screw Holes
EE
Technical Specifications
For information on Cyberpower products, visit www.cyberpower.com
9
Model Name
PDU15M2F8R
PDU15M2F10R
PDU15M2F12R
PDU20M2F8R
PDU20M2F10R
PDU20M2F12R
PDU20MT2F8R
PDU20MT2F10R
PDU20MT2F12R
Input
Voltage
Max Current 15 A
Circuit Breaker 15 A
Plug Type NEMA 5-15P NEMA 5-20P NEMA L5-20P
Power Cord Length
Output
Voltage
Current 15 A
Outlet Type NEMA 5-15R
Fiters & Protection
EMI/RFI Filtration
Surge Suppression
Indicators
LED Indicators
Meter Readout
Physical
Environmental
Humidity
Altitude
Temperature
Safety Approvals
Certifications
Warranty
100 ~ 125 V
20 A
20 A
15 ft
100 ~ 125 V
20 A
NEMA 5-20R
N/A
N/A
N/A
Amperage
17.5" x 2.25" x 1.75" / 44.5 x 5.72 x 4.45 cm
ETL (test followed UL 1363)
RoHS
Lifetime
Operating 0 to 95% Non-condensing
Non-Operating 0 to 95% Non-condensing
Operating 0ft to 10,000ft
Non-Operating 0ft to 50,000ft
Operating 32F to 95F
Non-Operating 5F to 113F
Dimension (WxDxH)

CyberPower PDU15B8R Specifications

General

Maximum current	15 A
AC input frequency	50 - 60 Hz
Nominal input voltage	120 V
Power plug	NEMA 5–15P
AC outlet types	NEMA 5–15R
AC outlets quantity	8 AC outlet(s)
PDU types	Basic
Product color	Black
Rack capacity	1U
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m
Storage temperature (T-T)	-15 - 45 °C
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Certification	UL1363, CSA C22.2
LED indicators	Yes

Weight and Dimensions

Weight (imperial)	3.5 lbs
Dimensions (W x D x H) (imperial)	17.5 x 1.5 x 1.75 \
