CyberPower PDU15B8R User Manual

Basic Series
Product Features
Front View
Back View
A B
A. Mounting Bracket
B. Back Outlets
C. External Site Ground
A. Mounting Bracket
B. Circuit Breaker
A B C D
D. AC Power Cord
E.
EE
D. AC Power Cord
E. Cord Retention Tray
Screw Holes
EE
Technical Specifications
For information on Cyberpower products, visit www.cyberpower.com
7
Model Name
PDU15B8R
PDU15B10R
PDU15B12R
PDU20B8R
PDU20B10R
PDU20B12R
PDU20BT8R
PDU20BT10R
PDU20BT12R
Input
Voltage
Max current
15 A
Circuit Breaker 15 A
Plug Type NEMA 5-15P NEMA 5-20P NEMA L5-20P
Output
Voltage
Current 15 A
Outlet Type NEMA 5-15R
Indicators
LED Indicators
Meter Readout
Physical
Environmental
Humidity
Altitude
Temperature
Safety Approvals
Certifications
Warranty
ETL (test followed UL 1363)
RoHS
Lifetime
Operating 0 to 95% Non-condensing
Non-Operating 0 to 95% N
on-condensing
Operating 0ft to 10,000ft
Non-Operating 0ft to 50,000ft
Operating 32F to 95F
Non-Operating 5F to 113F
N/A
17.5" x 1.5" x 1.75" / 44.5 x 3.81 x 4.45 cm
15 ft
N/A
100 ~ 125 V
20 A
NEMA 5-20R
100 ~ 125 V
20 A
20 A
Power Cord Length
Dimension (WxDxH)

CyberPower PDU15B8R Specifications

General

Maximum current	15 A
AC input frequency	50 - 60 Hz
Nominal input voltage	120 V
Power plug	NEMA 5–15P
AC outlet types	NEMA 5–15R
AC outlets quantity	8 AC outlet(s)
PDU types	Basic
Product color	Black
Rack capacity	1U
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m
Storage temperature (T-T)	-15 - 45 °C
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Certification	UL1363, CSA C22.2
LED indicators	Yes

Weight and Dimensions

Weight (imperial)	3.5 lbs
Dimensions (W x D x H) (imperial)	17.5 x 1.5 x 1.75 \
