INSTALLATION
5. (Optional) To connect an
environmental sensor, use a
RJ45 Ethernet cable. Connect
one end to the Universal port
on the RMCARD and the other
end into the sensor. For more
information, please see the
ENVIROSENOR user’s manual.
NOTE: The CyberPower Remote Management Card is hot-swappable, so you
do not need to turn o the device to install it.
NOTE: Please do not remove or modify SDCARD on the back. CyberPower is
not responsible for any unauthorized modification to RMCARD400/401.
4. Connect an Ethernet cable to
the Ethernet port of the
CyberPower Remote
Management Card.
3. Insert and tighten the
retaining screws.
2. Install the CyberPower
Remote Management Card
into the expansion slot.
1. Remove the two retaining
screws of the expansion
slot, and then remove the
cover.
Step 1. Hardware Installation
3
RMCARD400/401
CyberPower
Universal
Tx/Rx
RMCARD400
sal
Tx/Rx
CyberPower
CARD400
Tx/Rx
Link
Universal
RMCARD400
CyberPower
To Next Page
