Installation Guide
Step 1. Hardware Installation
Note: The CyberPower Remote Management Card is hot-swappable, so you do not need
to turn off the UPS to install it.
Note: Please do not remove or modify SDCARD on the back. CyberPower is not
responsible for any unauthorized modification to RMCARD400/401.
1. Remove the two retaining screws from the expansion
slot and remove the cover.
2. Install the CyberPower Remote Management Card
into the expansion slot.
3. Insert and tighten the retaining screws.
4. Connect an Ethernet cable to the Ethernet port of
the CyberPower Remote Management Card.
5.
(Optional)
To connect an environmental sensor,
use a RJ45 Ethernet cable. Connect one end to the
Universal port on the RMCARD and the other end
into the sensor. For more information, please see the
ENVIROSENOR/SNEV001
Note: Please only connect a CyberPower
ENVIROSENOR/SNEV001 or the supplied
RJ45/DB9 Serial Connection Cable to the
Universal port on the RMCARD.
RMCARD400/401
To Next Page
