5. You will need to enter a User Name and Password for the Remote Management Card in
the authentication window, as shown in Figure 2.
- Default user name: cyber
- Default password: cyber
Figure 2. The Device Network setting window.
6. You can modify the IP Address, Subnet Mask, and Gateway address for the Device MAC
Address listed in the Device Network Settings window, as shown in Figure 3. The factory
default IP Address is 192.168.20.177 and the default Subnet Mask is 255.255.255.0.
Figure 3. Authentication window.
7. Modify the IP, subnet mask or gateway address. Enter the new addresses into the
8. In case the change is not successful, for example, if the IP address change is
unsuccessful you will see a warning message. Attempt to make the desired changes
again. If the problem persists, please see the Troubleshooting section for help.
