CyberPower SMART APP SINEWAVE UPS Series User Manual

4
Front Panel
1. Power Switch
2. Toolless Battery Access Door
3. LCD Module
4. Front Panel Access Tabs
5. Faceplate
Rear Panel
1. Battery Backed and Surge Protected Outlet
2. Output Circuit Breaker
3. SNMP/HTTP Network Slot
4. Cloud Monitoring (Ethernet Port)
5. Input Circuit Breaker
6. AC Inlet
7. BM Port
8. Dry Contact
9. Serial Port
10. USB Port
11. EPO/ROO Port
12. TVSS Screw
13. Extended Battery Module Connector Socket

PR750RT2UC / PR1000RT2UC / PR1500RT2UC PR2000RT2UC
PR2200RT2UC PR3000RT2UC
PR750RTXL2UC / PR1000RTXL2UC PR1500RTXL2UC
5 4
21
3
1 2 3 4 5 6
89101112
1 2 3 4 5 6
89101112
89101112
1 2 3 4 5 6
89101112
1 2 3 4 5 6
48VDC 60A MAX
8910111213 7
1 2 3 4 5 6
8910111213 7
1 2 3 4 5 6
PRODUCT OVERVIEW
BASIC CONFIGURATION
BM Port
Connection port for built-in battery management module on extended battery module.

CyberPower SMART APP SINEWAVE UPS Series Specifications

General

Brand	CyberPower
Model	SMART APP SINEWAVE UPS Series
Category	UPS
Language	English
