8
Local Monitoring
Connect either the USB cable or Serial cable to the corresponding port on the UPS and on the computer with
PowerPanel Business software installed. PowerPanel Business software is available on our website. Please go to
www.cyberpowersystems.com/products/software/power-panel-business for the free download.
Note: USB and Serial port cannot be used simultaneously. Serial port will be disabled if the USB port is used.
Remote Monitoring
This product is equipped with a SNMP/HTTP network slot. If you would like to control the UPS from a remote location,
especially under a private network, a CyberPower Remote Management Card (RMCARD) is required. For more
information, visit www.cyberpowersystems.com.
Cloud Monitoring
This product features an Ethernet port for Cloud Connection, which makes it easy to monitor CyberPower UPS
systems from anywhere. Follow below steps to get your UPS on Cloud.
1. Hardware installation: Connect the Cloud Monitoring (Ethernet Port) on the UPS rear panel to a wall jack or
network switch using a suitable Ethernet cable.
LED Indicators Conditions
Link
Off The UPS is not connected to the Network.
On (Yellow) The UPS is connected to the Network.
Tx/R x
Off The Cloud Monitoring (Ethernet Port) is not powered.
On (Green) The Cloud Monitoring (Ethernet Port) is powered.
Flashing - Receiving/transmitting data packet
2. Application installation: Install PowerPanel Cloud App on your smartphone and then launch the application.
PowerPanel Cloud application is available for download on the Apple App Store or Google Play.
iOS Android
3. Sign up and login.
Cloud
NETWORK OPERATION
