CyberResearch MXGE Series - Audio Connector; Table 4-6: Audio CD in Connector Pinouts; Figure 4-5: Audio CD in Connector Pinouts (4-Pin)

CyberResearch
®
Motherboards MXGE Series
CyberResearch, Inc. 51
25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024
Branford, CT USA www.cyberresearch.com
CN Type:
10-pin header
CN Location:
See Figure 4-5
CN Pinouts:
See Table 4-6
The 4-pin audio CD in connector is connected to an external audio CD device for the input
and output of audio signals from a CD player to the system.
Figure 4-5: Audio CD In Connector Pinouts (4-pin)
PIN NO. DESCRIPTION
1 CD Signal In (Left)
2 Ground
3 Ground
4 CD Signal In (Right)
Table 4-6: Audio CD In Connector Pinouts
4.2.5 Audio Connector
CN Label:
CN3
CN Type:
10-pin header (2x5)
CN Location:
See Figure 4-6
