A42 GND B42 SERR
A43 PAR B43 +3.3V
A44 AD15 B44 C/BE1
A45 +3.3V B45 AD14
A46 AD13 B46 GND
A47 AD11 B47 AD12
A48 GND B48 AD10
A49 AD9 B49 GND
A52 C/BE0 B52 AD8
A53 +3.3V B53 AD7
A54 AD6 B54 +3.3V
A55 AD4 B55 AD5
A56 GND B56 AD3
A57 AD2 B57 GND
A68 AD0 B68 AD1
A59 +5V B59 +5V
A60 REQ64 B60 ACK64
A61 +5V B61 +5V
A62 +5V B62 +5V
Table 4-16: PCI Slot
4.2.15 PCI Express x16 Slot
CN Label:
PCIE2
CN Type:
164-pin PCIe x16 slot
CN Location:
See Figure 4-26
CN Pinouts:
See Table 4-17 (Side A) Table 4-18 (Side B)
PCIe x16 expansion devices can be inserted into the PCIe x16 slot.
