CYBEX Pallas M-FIX User Manual

42
PRESS!
L.S.P.
y
2
1
3
o
A
ACTIVATING THE L.S.P.
The “Linear Side Protection” system (L.S.P.) can be extended in two steps by
pressing the L.S.P. button(s). Together with the initial position, this provides a total of
three different L.S.P. settings.
To push the L.S.P. back into the housing, press the L.S.P. button again and push the
L.S.P. back into the starting position.
Note! Always activate the L.S.P. on the side of the seat facing the car door (see
illustration).
REMOVAL OF THE CYBEX PALLAS M-FIX
Perform the installation steps in the reverse order.
Note! By folding in the locking arms (o), you are not just protecting the vehicle seat
but also the locking arms of the ISOFIX CONNECT system from dirt and damage.
• Unlock the ISOFIX locking arms (o) on both sides by pushing the red
release buttons (y) and pulling them back simultaneously.
• Pull the seat out of the feed-in aids (u).
• Rotate the locking arms (o) 180°.
• Operate the adjustment lever (c) on the frame (w) of the CYBEX PALLAS M- x and
push the locking arms in as far as they will go.

CYBEX Pallas M-FIX Specifications

General

Certification	ECE R-44/04, Supplement 7
Mounting type	ISOFIX
Product color	Black
Car seat group	1-2-3 (9 - 36 kg; 9 months - 12 years)
Side protection	Yes
Belt fastening type	3-point

Weight and Dimensions

Depth	454 mm
Width	540 mm
Height	700 mm
Weight	9300 g
