CYCMOTOR PHOTON - Torque Requirements

Crank Arm BoltsA
B
C
D
Lockring
Left BB Cup
A-Frame Bolts
Tighten by hand
40 - 50 N.m.
5 - 10 N.m.
25 - 30 N.m.
A
B
C
D
Used For
Quantity
M15 Bolts
Hex Socket Head M4*25
Crank Arms
A-Frame
2
2
25
