Cyrus Pre - Specifications; Audio Performance

TROUBLESHOOTING Cyrus Pre
English
22
AUDIO PERFORMANCE
Input Sensitivity ........ Line .................................... 200mV
Phono MM ........................ 2.75mV
Phono MC (optional) .......... 200
µ
V
Input Impedance ........ Line .................................... 12.5k
Ω
Phono .................................... 47k
Ω
Input Capacitance Line ......................................100pF
Phono MM ...........................100pF
Phono MC (optional) ... 22pF-10nF
Volume Control Accuracy....................................+/-0.2dB
Channel Balance...................................................+/-0.2dB
Freq Response (-3dB) Line ...........................1Hz, 100kHz
RIAA accuracy Phono MM .......................+/-0.1dB
Phono MC (optional) .......+/-0.1dB
THD+N Line ....................................0.005%
(20Hz-20kHz)
Signal to Noise Ratio Line ...................................105dBA
(A-WTD) Phono MM ..........................87dBA
(A-WTD) Phono MC (optional) ..........78dBA
Input overload Line (ref 500mV) ...................20dB
Phono MM (ref 5mV) ............26dB
Phono MC (ref 500
µ
V)..........20dB
Voltage ........................ See the label at the rear of the unit
Power consumption.....................................................11W
Safety Requirements ............................................... IEC 65
Dimensions (WxHxD) ........................ 215 x 75 x 365 mm
Weight .......................................................................3.1Kg
Material ...................................................Magnesium alloy
and Aluminium alloy
The company reserves the right to change this specification without prior notice.
POWER SUPPLY
ENCLOSURE
Part No. PR-MANUL/Iss.01-9505 File:7LEN5504.WIM
