6
•
End stop: a physical stopper preventing the gate from running off the end of the rail and causing
injury or damage.
•
Intercom: equipment that allows communication between the gate and the house.
•
LCD Screen: indicates information regarding the operator status.
•
Manual override: allows the gate to be moved manually.
•
Party-mode: allows the gate to remain open even when auto-close is selected.
•
Positive close:
This means that the gate will close up against the end stop / gate post leaving no gap
between the gate and the stop. This ensures that any potential electrical contacts of an electric fence
make a solid connection when the gate is closed.
GENERAL INFORMATION cont.
GENERAL SITE LAYOUT
1. End stop - minimum 70mm high
2. Anti-lift device / rollers
3. Rail
4. Gate operator.
5. Magnet
6. Rack
7. Goose neck with intercom gate station
8. Catch bracket
9. DuraOptics Infrared Safety Beams
10. 80mm wheels.
11. Conduit carrying electrical cables (max. 16volts only)
12. Pillar courtesy lights
10
1
5
8
7
6
3
4
2
9
11
11
12
