D.A.C.E SOLO User Manual

7
OPERATOR LAYOUT
A. Conduit entry holes.
B. 4 Holes for bolting the plate to the concrete
plinth.
C. Jacking bolts to secure the operator to the
plate and for height adjustment.
C.
A.
B.
SOLO/SPRINT
FOUNDATION
PLATE
A. 12V 7AH Battery
B. LCD Screen
C. Main PC Board
D. 12V DC Electric Motor
E. Manual override access door
with lock
F. Override access key
G. Transformer
H. Cable risers
B.
H.
C.
A.
D.
E.
F.
G
SOLO/SPRINT
OPERATOR

D.A.C.E SOLO Specifications

General

Brand	D.A.C.E
Model	SOLO
Category	Remote Control
Language	English
