Manual del Usuario / D series amplifiers/ User’s Manual
14
APPENDIX II
T LINE - OPERATING INSTRUCTIONS (Only D-10)
The T Line chassis can be configured with up to 4 transformers of 500W at 100V output, 4 ohms input.
Other specifications (70V/50V) are available to special order.
The power rating of each channel is printed on the rear panel.
The connections are via 4-pole SPEAKON connectors (NL4FC).
INPUTS (4 ohms) are: +1 = HOT, -1 = COLD
OUTPUTS (100V) are: +2 = HOT, -2 = COLD
THERE ARE NO USER-SERVICEABLE PARTS INSIDE AND NO MAINTENANCE IS REQUIRED.
IN THE EVENT OF A FAILURE, REFER TO A QUALIFIED SERVICE ENGINEER.
Parts are available from D.A.S.Audio, S.A.
TECHNICAL SPECIFICATION
T LINE
Rated power handling 500W
@ input impedance - 4W
Output impedance rated @ 100V (Standard) 20.0W
@ 70V (Special) 9.8W
@ 50V (Only) 5.0W
Frequency response 50Hz-16kHz ± 1dB
Distortion (THD) 50Hz-16kHz <0.03%
Weight (each) Chassis only 12kgs
500W transformer 2.8kgs
Dimensions (mm) - 2U 88 x 482 x 428
When mounting the amplifier in a rack or enclosure, ensure that :-
The rear of the unit is adequately supported. The brackets which are supplied fit standard 19 inch
(483mm) rack mounting systems. THE FRONT PANEL IS NOT CAPABLE OF SUPPORTING THE UNIT ON
ITS OWN.
(The general D-10 safety warnings, precautions and service advice also apply to the T LINE.)
