8
Desktop Installation
When installing the DES-1024D on a desktop or shelf, the rubber feet
included with the device should be attached first, to minimize scratching or
scarring of the surface on which the Switch is placed. Attach these
cushioning feet on the bottom at each corner of the device. Allow enough
ventilation space between the device and the objects around it.
Fast Ethernet Switch installed on a Desktop or Shelf
Rack Mounting
The DES-1024D can be mounted in an EIA standard-size 19-inch rack, in a
wiring closet with other equipment. Attach the mounting brackets on each
side of the Switch’s front panel (as shown in the illustration below), and
secure them with the screws provided.
