D-Link 24-Port 10/100/1000Mbps Ethernet Switch DES-1024D User Manual

ii
TABLE OF CONTENTS
About This Guide ......................................................... 1
PURPOSE ..........................................................................................1
TERMS/USAGE .................................................................................1
OVERVIEW OF THIS USER’S GUIDE................................................1
Introduction .................................................................. 2
FAST ETHERNET TECHNOLOGY.....................................................2
SWITCHING TECHNOLOGY .............................................................3
FEATURES ........................................................................................4
IEEE
801.1P AND QOS…...….……………………………………5
Unpacking and Setup.................................................... 4
UNPACKING .....................................................................................7
SETUP ...............................................................................................7
DESKTOP INSTALLATION................................................................8
RACK MOUNTING............................................................................8
Identifying External Components............................... 10
FRONT PANEL................................................................................10
REAR PANEL..................................................................................11
Technical Specifications ............................................. 12
Technical Specifications ............................................. 13

D-Link 24-Port 10/100/1000Mbps Ethernet Switch DES-1024D Specifications

General

Switching Capacity	48 Gbps
MAC Address Table	8K entries
Switch Type	Unmanaged
Packet Buffer Memory	512 KB
Throughput	35.7 Mpps
Operating Humidity	10% to 90% non-condensing
Ports	24 x 10/100/1000Mbps
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Dimensions	280 x 180 x 44 mm
Operating Temperature	0 to 40 °C
