D-Link 24-Port 10/100/1000Mbps Ethernet Switch DES-1024D User Manual

13
TECHNICAL SPECIFICATIONS
Performance
Transmits
Method:
Store-and-forward
RAM Buffer: 1.25 MBits per device
Filtering
Address Table:
8K entries per device
Packet Filtering/
Forwarding
Rate:
10Mbps Ethernet: 14,880/pps
100Mbps Fast Ethernet: 148,800/pps
MAC Address
Learning:
Automatic update

D-Link 24-Port 10/100/1000Mbps Ethernet Switch DES-1024D Specifications

General

Switching Capacity	48 Gbps
MAC Address Table	8K entries
Switch Type	Unmanaged
Packet Buffer Memory	512 KB
Throughput	35.7 Mpps
Operating Humidity	10% to 90% non-condensing
Ports	24 x 10/100/1000Mbps
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Dimensions	280 x 180 x 44 mm
Operating Temperature	0 to 40 °C
