D-Link 24-Port 10/100/1000Mbps Ethernet Switch DES-1024D - Technical Specifications; General; Physical and Environmental

12
TECHNICAL SPECIFICATIONS
General
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.1p Compliance
Protocol CSMA/CD
Data Transfer
Rate
Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full- duplex)
Topology Star
Network Cables
10BASET: 2-pair UTP Cat. 3,4,5, EIA/TIA- 568 100-ohm STP
100BASE-TX: 2-pair UTP Cat. 5, EIA/TIA-568 100-ohm STP
Number of
Ports
24 x 10/100Mbps Auto-MDI ports
Physical and Environmental
AC inputs 100 to 240 VAC, 50 or 60 Hz internal universal power supply
Power
Consumption
7.9 watts. (max.)
Temperature
Operating: 0° ~ 40° C (32º to 104º F), Storage: -10° ~ 70° C
(14º to 158º F)
Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions Width: 11.02 in. (280mm)
Depth: 7.09 in. (180mm)
Height: 1.73 in. (44mm)
EMI: FCC Class A, CE Mark Class A, VCCI Class A
Safety CUL
