D-Link 24-Port 10/100/1000Mbps Ethernet Switch DES-1024D User Manual

11
 100Mbps (green)
This green LED indicator illuminates when the port is connected to a
100Mbps Fast Ethernet station. The LED does not illuminate when the port is
connected to 10Mbps Ethernet station.
Twisted-Pair Ports
These ports support automatic MDI/MDIX crossover detection function
providing true ‘plug and play’ connectivity, which eliminates the need for
crossover cables or uplink ports. Any port can be simply plugged to a server,
workstation, or hub using the usual straight-through, twisted-pair cable.
Rear Panel
AC Power Connector

D-Link 24-Port 10/100/1000Mbps Ethernet Switch DES-1024D Specifications

General

Switching Capacity	48 Gbps
MAC Address Table	8K entries
Switch Type	Unmanaged
Packet Buffer Memory	512 KB
Throughput	35.7 Mpps
Operating Humidity	10% to 90% non-condensing
Ports	24 x 10/100/1000Mbps
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Dimensions	280 x 180 x 44 mm
Operating Temperature	0 to 40 °C
