4
latencies. Routers have also been used to segment local area networks, but
the cost of a router, the setup and maintenance required make routers
relatively impractical. Today switches are an ideal solution to most kinds of
local area network congestion problems.
Features
The DES-1024D is a high-performance switch designed specifically for
environments where traffic on the network and the number of users increase
continuously.
9 24-port 10/100BASE Ethernet Switch with RJ-45 connectors
9 Supports Auto-negotiation of speed and duplex modes for each
port
9 Supports Auto-MDI/MDI-X on each port, eliminating the need for
cross over cables or uplink ports
9 Wire-speed reception and transmission
9 Store-and-Forward switching method
9 Integrated address Look-Up Engine, supports 8K MAC addresses
9 Supports 1.25 Mbits RAM for data buffering
9 Front-panel diagnostic LEDs
9 IEEE 802.3x flow control for full-duplex
9 Back pressure flow control for half-duplex
9 IEEE 802.1p Priority support
IEEE802.1P AND QOS
The DES-1024D Switches support 802.1p priority queuing Quality of Service.

D-Link 24-Port 10/100/1000Mbps Ethernet Switch DES-1024D Specifications

General

Switching Capacity	48 Gbps
MAC Address Table	8K entries
Switch Type	Unmanaged
Packet Buffer Memory	512 KB
Throughput	35.7 Mpps
Operating Humidity	10% to 90% non-condensing
Ports	24 x 10/100/1000Mbps
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Dimensions	280 x 180 x 44 mm
Operating Temperature	0 to 40 °C
