4 DAP-1665 Install Guide
Hardware Overview
LEDs
4321
1 Power LED
A solid light indicates a proper connection to the power
supply.
2 2.4GHz Wireless LED
A solid green light indicates the wireless function is
working. The light will be o during device reboot or if the
wireless radio is disabled.
3 5GHz Wireless LED
A solid green light indicates the wireless function is
working. The light will be o during device reboot or if the
wireless radio is disabled.
4 LAN LED
A solid light indicates a connection to an Ethernet-
enabled device.
