Hardware Overview
1. Camera lens 8. Antenna connector (DCS-2121 only)
2. Focus ring 9. WPS button and LED (DCS-2121 only)
3. Status LED 10. Camera base mount
4. Microphone
5. Wireless antenna (DCS-2121 only)
6. SD Card slot
7. Reset button
8 9
10
1
2
3
6
7
5
4
Front Back
