D-Link DCS-2132L Manual

Introduction
D-Link DCS 2132L is a very popular 1 MP (1280x800 Pixel) H.264 Wireless IP Camera with night-
vision of up to 15 feet and excellent video / image quality. It supports both image snapshot and
video/audio recording. You can use H.264 encoded MP4 video format for best compatibility with video
viewers. WPS is available for easy connecting to Wi-Fi.
Basic camera information
Video / image resolution
1280x800,1280x720,800x600,800x450,
640x480,640x360,320x240;320x180
Audio recording
Supported (2-way)
Image upload frequency
1 image/s
Video frame rate
1, 4, 7, 15, 30 fps
Night-vision
Up to 15 feet
Image snapshot recording
Supported, but only supports 1 image/s. (Continuous recording is
not fully supported.)
Video clip recording
Supported. (Continuous recording is not fully supported)
Motion detection
Supported for both image and video recording
Continuous recording
Continuous recording is not fully supported. It can record 1
minute video/2 minutes, or 10 images/minute.
Supported video format
.MP4
Connection type
Wi-Fi and Ethernet cable; supports WPS
PoE (Power on Ethernet)
No
Indoor / outdoor
Indoor
Lowest pricing (as of
7/31/2015)
$129.99
Note: This document is not designed to replace the manufacturers’ product manual. The
information provided is based on our knowledge of the model D-Link DCS 2132L. It may not be
accurate or completely up-to-date. Users shall contact the manufacturer for all camera-related
issues and contact us only for CameraFTP-related (i.e. Cloud Service / FTP) issues. Most of the
setup steps below are camera related and are very trivial. If you have finished these basic steps
before, then you can skip Steps 1 and 2. CameraFTP’s service can be configured in just 3 steps
(i.e. Steps 3, 4 and 5).
Step 1: Connect Camera to the Network and Find Its IP Address
1.1 Connect Camera to the Network
There are two ways to connect the IP camera to the Wi-Fi network.

D-Link DCS-2132L Specifications

General

Maximum resolution	1280 x 800 pixels
Supported video modes	720p
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	176 x 144, 320 x 240, 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Minimum illumination	0 lx
Field of view (FOV) angle	66 °
Sensor type	CMOS
Optical sensor size	1/4 \
Digital zoom	10 x
Optical zoom	- x
Focus adjustment	2.0
Fixed focal length	3.45 mm
Active tampering alarm	No
Video motion detection	Yes
Compatible memory cards	microSD (TransFlash), microSDHC
LED type	IR
Night vision distance	5 m
Type	IP security camera
Certification	CE, CE LVD, FCC, C-Tick
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Box
Product color	White
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Wi-Fi standards	Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Supported network protocols	HTTP, FTP, TCP/IP, SMTP, DHCP, PPPoE, DDNS, UPnP, RTP / RTSP/ RTCP, QoS, CoS, IGMP
AC input voltage	100-240 V
DC output current	1.2 A
DC output voltage	+5V
AC input frequency	50 - 60 Hz
Power consumption (typical)	3.65 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1329 mm
Pallet height (sea)	1926 mm
Pallet gross weight (air)	255856 g
Pallet gross weight (sea)	372784 g
Quantity per pallet (air)	420 pc(s)
Quantity per pallet (sea)	630 pc(s)
Shipping (inner) case width	324 mm
Shipping (inner) case height	199 mm
Shipping (inner) case length	538 mm
Shipping (inner) case weight	5568 g
Shipping (inner) case net weight	4818 g
Number of cartons per pallet (air)	42 pc(s)
Number of cartons per pallet (sea)	63 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	58 mm
Width	89 mm
Height	127 mm
Weight	116 g
Package depth	160 mm
Package width	152 mm
Package height	102 mm
Package weight	481.8 g
