D-Link DCS-8000LHV2 User Manual

12D-Link DCS-8000LHV2 User Manual
Section 2 - Installation
Place the camera into the mount, ensuring that the power port
in the back is exposed. Plug the USB power cable into the camera
ensuring it is plugged in all the way.
4/
Align the markings on the camera mount and baseplate. Press the
camera mount onto the baseplate.
5/
Twist the camera mount slightly to the right to lock it onto the
baseplate. Adjust the camera angle, then tighten the screw on the
left to lock it in place.
6/

D-Link DCS-8000LHV2 Specifications

General

Sensor type	CMOS
Progressive scan	Yes
Number of sensors	-
Optical sensor size	1/2.7 \
Fixed focal length	3.28 mm
Maximum aperture number	2.2
LED type	IR
Night vision distance	5 m
Type	IP security camera
Certification	CE, LVD, FCC Class B, IC, RCM, NCC
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Minimum illumination	0 lx
Audio formats supported	AAC, LC-AAC
Security algorithms	WPA, WPA2, WPA3
Alert notification type	Snapshot alert message, Text alert message
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video compression formats	H.264
Supported graphics resolutions	1920 x 1080 (HD 1080)
Ethernet LAN	No
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	2400 Mbit/s
Supported network protocols	IPv4, IPv6, DHCP, Bonjour (mDNS and DNS-SD), ONVIF Profile S, RTSP, RTCP, RTP/SRTP, HTTPS
Mobile operating systems supported	Android, iOS
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (max)	4 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Mounting type	Desk/Wall
Product color	White
LED indicators	Status
Number of cameras	1
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	37 mm
Width	43 mm
Height	95 mm
Weight	59 g
Cable length	1.5 m
