10/100 Fast Ethernet Switch User’s Guide
Connecting The Switch
19
10BASE-T Hub
For a 10 BASE-T hub, the Switch’s LED indicators should illuminate the
following:
♦
100M LED speed indicator is OFF
.
♦
Link/Act indicator is ON.
♦
FDX indicator is OFF.
100BASE-TX Hub
For a 100Base-TX hub, the Switch’s LED indicators should illuminate the
following:
♦
100M LED speed indicator is ON
.
♦
Link/Act is ON.
♦
FDX LED indicator is OFF.
Hub without Uplink (MDI-II) port
If a hub is not equipped with an Uplink (MDI-II) port, then a connection
can be made using either straight cable or crossover cable (see
Appendix B
,
Pin Specification
for cable requirement).
