10/100 Fast Ethernet Switch User’s Guide
32
Technical Specifications
General
Network Cabling:
10BASE-T:
2-pair UTP Cat. 3,4,5 (100 m)
EIA/TIA- 568 100-ohm STP (100 m)
100BASE-TX:
2-pair UTP Cat. 5 (100 m)
EIA/TIA-568 100-ohm STP (100 m)
100BASE-FX:
Multi-mode (62.5/125
µ
m or 50/125
µ
m) fiber cabling with an IEEE
recommended SC connector
Number of Ports: DES-1016: 16 x 10/100 Mbps ports
DES-1024: 24 x 10/100 Mbps ports
Media Interface
Exchange:
2 x MDI-II RJ-45 shared with port 3x and 4x
Physical and Environmental
AC inputs: 100 - 240 VAC, 50/60 Hz (internal universal power supply)
Power Consumption: 50 watts maximum
DC fans: 2 built-in 40x40 mm fans
Operating Temperature: 32
°
~ 122
°
F (0
°
~ 50
°
C)
Storage Temperature: -22
°
~ 140
°
F (-30
°
~ 60
°
C)
Humidity: 5% ~ 95% non-condensing
