DES-3226S Layer 2 Fast Ethernet Switch User’s Guide
105
Network Monitoring
The DES-3226S provides extensive network monitoring capabilities that can be viewed from the under Network Monitoring
menu.
Port Utilization
The Port Utilization window shows the percentage of the total available bandwidth being used on the port. Port utilization
statistics may be viewed using a line graph or table format.
To view the port utilization, click on the Network Monitoring folder and then the Statistics folder and then the Port
Utilization link:
Figure 6 - 92. Port Utilization Line Chart Figure 6 - 93. Port Utilization Table
Select the desired port by clicking on the front panel display. The Update Interval field sets the interval at which the error
statistics are updated.
The following field can be set:
Parameter Description
Update Interval
<Suspend>
The time between updates received from the Switch, in seconds. Suspend stops the
updates. The default is Suspend.
