DES-3550 Fast Ethernet Layer 2 Switch
Figure 8- 1. Port Utilization window
The following field can be set:
Parameter Description
Time Interval
Select the desired setting between 1s and 60s, where "s" stands for seconds. The
default value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default
value is 200.
Click Clear to refresh the graph. Click Apply to set changes implemented.
CPU Utilization
The CPU Utilization displays the percentage of the CPU being used, expressed as an integer percentage and calculated as
a simple average by time interval. To view the CPU Utilization window, open the Monitoring folder and click the CPU
Utilization link.
143
