DES-3550 Fast Ethernet Layer 2 Switch
Figure 8- 22. Authenticator State window – MAC-Based 802.1x
This window displays the Authenticator State for individual ports on a selected device. To select unit within the switch
stack, use the pull-down menu at the top of the window and click Apply. A polling interval between 1 and 60 seconds can
be set using the drop-down menu at the top of the window and clicking OK.
The information on this window is described as follows:
Parameter Description
Auth PAE State
The Authenticator PAE State value can be: Initialize, Disconnected, Connecting,
Authenticating, Authenticated, Aborting, Held, Force_Auth, Force_Unauth, or N/A.
N/A (Not Available) indicates that the port's authenticator capability is disabled.
164
