D-Link DIR-506L User Manual

11D-Link DIR-506L User Manual
Section 2 - Installation
This wizard is designed to guide you through a step-by-step
process to congure your new D-Link router and connect to the
Internet.
Click Next to continue.
Initial Setup Wizard
If you chose Router mode, the DIR-506L will try to detect what
type of Internet connection you have and will ask you for the
related settings. Enter the settings for your connection and
click Next.
If your Internet connection cannot be detected(or if you click
the Prev button after the previous step), you will need to
select which type of Internet connection you have. Select your
Internet connection type, then click the Next button and enter
the related settings.
Note: Most cable modem connections use DHCP, and most
DSL modem connections use PPPoE. If you are not sure which
connection type you use or what settings to enter, contact your
Internet service provider.

D-Link DIR-506L Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	1
USB version	2.0
Rack mounting	No
DHCP client	-
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2, WPS
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	22.3 mm
Width	102.9 mm
Height	79.8 mm
Weight	125 g
