DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Overview
Back Panel
Figure 2. Back panel view.
Port Description
LAN 1-8 8 Ethernet ports to connect computers or network devices.
INTERNET
A port to connect to a cable or DSL modem or to a private Ethernet
line (it is recommended to use the cable included in the delivery
package).
USB A port for connecting a USB modem, a USB storage, or a printer.
RESET
A button to restore the factory default settings.
To restore the factory defaults, push the button (with the device turned
on), hold it for 10 seconds, and then release the button.
5V=2.5A Power connector.
The router is also equipped with two detachable antennas with RP-SMA connector.
