DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
Figure 125. The page for adding a rule for remote management.
You can specify the following parameters:
Parameter Description
IP address
A host or a subnet to which the rule is applied. To choose a device
connected to the router's LAN at the moment, select the relevant
value from the drop-down list (the field will be filled in
automatically).
Mask The mask of the subnet.
Protocol
The protocol available for remote management of the router.
Public port An external port of the router. You can specify only one port.
Click the Change button.
To edit a rule for remote access, click the relevant link. On the opened page, change the needed
parameters and click the Change button.
To remove a rule for remote access, click the relevant link. On the opened page, click the Delete
button.
