DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
Figure 128. The page for adding a rule for IP filtering.
You can specify the following parameters:
Parameter Description
IP filter rule editing
Name
A name for the rule for easier identification.
Protocol
A protocol for network packet transmission. Select a value from the
drop-down list.
Action
Select an action for the rule.
ACCEPT: Allows packet transmission in accordance with the
criteria specified by the rule.
DROP: Denies packet transmission in accordance with the criteria
specified by the rule.
IP Addresses
IP address range
Select the checkbox if you want to specify a range of IP addresses as
the source or destination IP address.
Page 160 of 197
