DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
Figure 40. Configuring PPTP WAN connection. The expert settings mode. The VPN section.
Parameter Description
Connection name
A name for connection for easier identification.
VPN
Connect automatically
Select the checkbox to enable auto-start of the connection upon the
boot-up of the router.
Username A username (login) to access the server.
Without authorization
Select the checkbox if you don't need to enter a username and
password to access the server.
Password
A password to access the server.
Password confirmation
The confirmation of the entered password (to avoid mistypes).
VPN server address
The IP or URL address of the PPTP or L2TP authentication server.
Page 55 of 197
