D-Link DSL-2740B User Manual

Section 3 - Configuration
D-Link DSL-2740B User Manual
80
STATIC ROUTE
Enter the destination network address, subnet mask, gateway
AND/OR available WAN interface then click "Apply" to add the
entry to the routing table.
DEFAULT GATEWAY
Select the proper wan interface as the system default gateway
from the drop-down menu. Click "Apply" button to save it.
RIP
To activate RIP service, select the desired RIP version and
operation, followed by placing a check in the 'Enabled' checkbox
for the interface. To stop RIP service, uncheck the ‘Enable’
checkbox for the interface. Click the 'Save/Apply' button to save
the configuration and to start or stop RIP.
NOTE: RIP cannot be configured on the WAN interface which has
NAT enabled (such as PPPoE).

D-Link DSL-2740B Specifications

ADSL Standards

downstream data rate	up to 8 Mbps
upstream data rate	up to 1 Mbps
G.lite downstream data rate	up to 1.5 Mbps
G.lite upstream data rate	up to 512 Kbps
G.dmt.bis downstream data rate	up to 12 Mbps
G.dmt.bis upstream data rate	up to 12 Mbps

ADSL2 Standards

full rate downstream data rate	up to 24 Mbps
full rate upstream data rate	up to 1 Mbps

Wireless LAN

wireless speed	up to 300 Mbps
frequency range	2.4 GHz to 2.484 GHz
antennas	2 non-detachable dipole
