DSL-3785
16
ITALIANO
Configurazione PRODOTTO
Passaggio 1
PosizionareDSL-3785 vicino al PC e a una presa telefonica a parete
che fornisca il servizio DSL. Per una migliore copertura wireless,
sistemare il router in un'area priva di ostacoli.
PC
DSL-3785 Telefono
Passaggio 2
Inserire un'estremità del cavo telefonico DSL nella porta DSL che si
trova sul retro del router del modem e inserire l'altra estremità nella
presa a parete telefonica.
PC
DSL-3785 Telefono
IMPOSTAZIONE HARDWARE
Passaggio 3
Collegare l'alimentatore in dotazione al router modem e a una
presa elettrica, quindi premere il pulsante di alimentazione. I LED
del dispositivo si illumineranno. Attendere circa un minuto prima di
procedere con il passaggio 4.
DSL-3785
Accensione
PC
Passaggio 4
Collegare un'estremità del cavo Ethernet in dotazione alla porta
1
sul retro del router modem e l'altra estremità alla porta Ethernet del
computer.
Se si congura DSL-3785 utilizzando un laptop o un dispositivo
mobile
, collegarlo mediante il nome della rete Wi-Fi e la password
stampati sull'etichetta posta sul retro del router.
DSL-3785Accensione
PC
REQUISITI DI SISTEMA
Servizio Internet ADSL/VDSL
Computer con:
Microsoft Windows
®
10/8/7/Vista/XP SP3 o Mac con OS X 10.7 o superiore
Internet Explorer 8, Edge 25, Firefox 20, Safari 4 oppure Chrome 17 o versioni successive
con Java installato e abilitato
PC

Other manuals for D-Link DSL-3785

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DSL-3785 and is the answer not in the manual?

D-Link DSL-3785 Specifications

General IconGeneral
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standardsWi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1167 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
WLAN data transfer rate (second band)866 Mbit/s
Ethernet LANYes
Networking standardsIEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Ethernet LAN interface typeGigabit Ethernet
Memory card slot(s)No
RJ-11 ports quantity1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports4
3G/4G USB modem compatibility-
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, Power, WLAN, WPS
Antennas quantity2
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Security algorithmsWPA, WPA2, WPS
AC input voltage100 - 240 V
Power source typeAC
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)10 - 95 %
CertificationCE, LVD
Weight and Dimensions IconWeight and Dimensions
Depth150 mm
Width210 mm
Height30.75 mm
Weight113.05 g
