D-Link DSL-3785 Quick Installation Guide

DSL-3785
49
HRVATSKI
POSTAVLJANJE PROIZVODA
Korak 1
Postavite svoj DSL-3785 blizu svog računala i telefonske utičnice
putem koje se pruža DSL usluga. Držite modem - usmjernik na
otvorenom području radi bolje pokrivenosti bežičnim signalom.
Osobno računalo
DSL-3785
Telefon
Korak 2
Priključite jedan kraj isporučenog DSL telefonskog kabela u DSL
priključak na pozadini modema - usmjernika, a drugi kraj priključite u
telefonsku utičnicu.
Osobno računalo
DSL-3785 Telefon
POSTAVLJANJE HARDVERA
Korak 3
Priključite isporučeni adapter napajanja u modem - usmjernik i u
električnu utičnicu i pritisnite gumb za uključivanje. LED lampice na
uređaju će se početi svijetliti. Pričekajte oko 1 minutu prije prelaska
na korak 4.
DSL-3785Napajanje
Osobno računalo
Korak 4
Priključite jedan kraj isporučenog Ethernet kabela u priključak
označen brojem
1
na pozadini modema - usmjernika, a drugi kraj
priključite u Ethernet priključak na vašem računalu.
Ako postavljate DSL-3785 koristeći prijenosnik ili mobilni
uređaj
, povežite ga koristeći korisničko ime i zaporku za Wi-
Fi mrežu ispisane na naljepnici koja se nalazi na pozadini vašeg
usmjernika.
DSL-3785
Napajanje
Osobno računalo
ZAHTJEVI SUSTAVA
• ADSL/VDSL internetska usluga
• Računalo sa sljedećim značajkama:
• Microsoft Windows
®
10/8/7/Vista/XP SP3 ili Mac s OS X 10.7 ili novijim
• Internet Explorer 8, Edge 25, Firefox 20, Safari 4, ili Chrome 17 ili novija verzija s instaliranom
i omogućenom Javom
Osobno računalo

D-Link DSL-3785 Specifications

General

Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	866 Mbit/s
Ethernet LAN	Yes
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Ethernet LAN interface type	Gigabit Ethernet
Memory card slot(s)	No
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
3G/4G USB modem compatibility	-
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, WLAN, WPS
Antennas quantity	2
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Security algorithms	WPA, WPA2, WPS
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, LVD

Weight and Dimensions

Depth	150 mm
Width	210 mm
Height	30.75 mm
Weight	113.05 g
